KLS B350CRIMPING MACHINE
KLS B350CRIMPING MACHINE
KLS B350CRIMPING MACHINE
KLS B350fast clamping machine, is a high-precision mass
production of clamping hose joint sharps with super self-lubricating friction plate,
Type:Fast ultra-thin hydraulic hose crimpers
Model | KLS B350 Hose Crimping Machine |
Crimping Range | 6-102(mm) (1/4''-4''inner diameter of hose) |
Crimping Force | 520(T) |
Hose Size | 1/4-2(inch) |
Max. Opening | 220mm |
Die Sets | 15sets |
Maximum Open Diameter | 145MM |
System Pressure | 35(Mpa) |
Accuracy | 0.01(mm) |
Work Efficiency | 800 pcs/h |
Standard Voltage | 220V/380v/415v(optional) |
Motor Power | 5.5KW |
size | 460×980×1680mm |
Item No.of dies | 14,16,19,22,26,30,34,39,45,51,57,63,69mm |
Weight | 830(KG) |
